SKU: UC-CAM-203-U2

$649.47 ex GST

The UC CAM 200 series cameras offer impressive picture quality in a smaller package. The features include advanced ISP processing algorithms to provide vivid images with a strong sense of depth, high resolution, and fantastic color rendition.

Key Features

  • Superb High-definition Image:   UC-CAM-200 Series employs 1/2.9 inch high quality CMOS sensor. Resolution is up to 1920×1080 with frame rate up to 30fps.
  • Various Optical Zoom Lens: UC-CAM-200 Series has 3X/10X optical zoom lens for options.
  • Leading Auto Focus Technology: Leading auto focus algorithm makes lens a fast, accurate and stable auto-focusing.
  • Low Noise and High SNR: Low Noise CMOS effectively ensure high SNR of camera video.Advanced 2D/3D noise reduction technology is also used to further reduce the noise, while ensuring image sharpness.
  • Multiple Control Interface: RS232, RS485; RS232 support daisy chain, convenient for installation on projects.
  • Multiple Control Protocols: Support VISCA, elco-D, Pelco-P and support auto-recognize protocol.
  • Low-power sleep function: Support low-power sleep/wake up,the consumption is lower than 400mW under sleep mode
  • IR Remote Control
  • Preset: Support up to 255 presets (10 presets by remote )


Specifications

Model
Number

UC-CAM-203

UC-CAM-210

Camera
Parameter







Sensor

1/2.9 Inch High
Quality CMOS Sensor

Effective
Pixels

2.07MP, 16:9

Video
Format

1920×1080P@30 fps/25fps; 1280×720P@30fps/25fps; 1024×576P@30fps/25fps;

960×540P@30fps/25fps;
800
×448P@30fps/25fps;
640
×360P@30fps/25fps;
320
×176P@30fps/25fps

Optical
Lens

3X Optical Lens

f3.35mm10.05mm

10X Optical Lens

f4.34mm41.66mm

View
Angle

 34.1°~110°

8.8°~
68.8
°

Iris

F1.73.0

F1.85 F2.43

Digital
Zoom

10X

Low
Illumination

0.5Lux(F1.8, AGC ON)

DNR

2D3DDNR

White
Balance

Auto / Manual/ One Push//3000K/3500K/4000K/4500K/5000K/5500K/6000K/6500K/7000K

Focus

Auto / Manual/ One Push/

Electronic
Shutter

Auto / Manual/

BLC

On/Off

WDR

OFF/ Dynamic Level Adjustment

Video
Adjustment

Brightness, Color, Saturation, Contrast,
Sharpness, B/W mode, Gamma curve

SNR

>55dB

Interface
and Protocol



Video
Output

USB2.0

Video
Stream

Dual Stream

Video
Compression

H.265, H.264, MJPG

Control
Port

RS232(Circuit), RS485

Control
Protocol

Protocol: VISCA/Pelco-D/Pelco-P

Power
Supply

HEC3800 Outlet (DC12V)

Power
Adapter

Input AC110V-AC220V, output DC12V/1.5A

Power
Input

DC12V±10%, 1A(Max)

Power
Consumption

12W(Max)

USB
characteristics



Support             operating

system

Windows 7,Windows8,Windows10,Mac OSX, Linux

Video
Compression

H.265, H.264, MJPG

USB          communication

protocol

UVC

PTZ
Parameter



Pan/Tile
Rotation

-170°~+170°, -30°~+30°

Pan/Tile
Controller Speed

0.1~60°/Second, 0.1~30°/Second

Preset Speed

Pan:60°/Second, Tilt: 30°/Second

Preset Numbers

255 Points Preset (10 points By Remote
Controller)

Other
Parameter



Working
Voltage



12V

Working
current



0.25A(max)

Power
Consumption



2.5W(max)



Specifications subject to change without notice.

Package Contents

  • 1 x USB PTZ Camera
  • 1 x 12V/1A Power adapter
  • 1 x User Manual
  • 1 x IR Remote Control
  • USB2 Cable
UC-CAM-210-Dimensions

Key Features

  • Superb High-definition Image:   UC-CAM-200 Series employs 1/2.9 inch high quality CMOS sensor. Resolution is up to 1920×1080 with frame rate up to 30fps.
  • Various Optical Zoom Lens: UC-CAM-200 Series has 3X/10X optical zoom lens for options.
  • Leading Auto Focus Technology: Leading auto focus algorithm makes lens a fast, accurate and stable auto-focusing.
  • Low Noise and High SNR: Low Noise CMOS effectively ensure high SNR of camera video.Advanced 2D/3D noise reduction technology is also used to further reduce the noise, while ensuring image sharpness.
  • Multiple Control Interface: RS232, RS485; RS232 support daisy chain, convenient for installation on projects.
  • Multiple Control Protocols: Support VISCA, elco-D, Pelco-P and support auto-recognize protocol.
  • Low-power sleep function: Support low-power sleep/wake up,the consumption is lower than 400mW under sleep mode
  • IR Remote Control
  • Preset: Support up to 255 presets (10 presets by remote )

Package Contents

  • 1 x USB PTZ Camera
  • 1 x 12V/1A Power adapter
  • 1 x User Manual
  • 1 x IR Remote Control
  • USB2 Cable
UC-CAM-210-Dimensions


Specifications

Model
Number

UC-CAM-203

UC-CAM-210

Camera
Parameter







Sensor

1/2.9 Inch High
Quality CMOS Sensor

Effective
Pixels

2.07MP, 16:9

Video
Format

1920×1080P@30 fps/25fps; 1280×720P@30fps/25fps; 1024×576P@30fps/25fps;

960×540P@30fps/25fps;
800
×448P@30fps/25fps;
640
×360P@30fps/25fps;
320
×176P@30fps/25fps

Optical
Lens

3X Optical Lens

f3.35mm10.05mm

10X Optical Lens

f4.34mm41.66mm

View
Angle

 34.1°~110°

8.8°~
68.8
°

Iris

F1.73.0

F1.85 F2.43

Digital
Zoom

10X

Low
Illumination

0.5Lux(F1.8, AGC ON)

DNR

2D3DDNR

White
Balance

Auto / Manual/ One Push//3000K/3500K/4000K/4500K/5000K/5500K/6000K/6500K/7000K

Focus

Auto / Manual/ One Push/

Electronic
Shutter

Auto / Manual/

BLC

On/Off

WDR

OFF/ Dynamic Level Adjustment

Video
Adjustment

Brightness, Color, Saturation, Contrast,
Sharpness, B/W mode, Gamma curve

SNR

>55dB

Interface
and Protocol



Video
Output

USB2.0

Video
Stream

Dual Stream

Video
Compression

H.265, H.264, MJPG

Control
Port

RS232(Circuit), RS485

Control
Protocol

Protocol: VISCA/Pelco-D/Pelco-P

Power
Supply

HEC3800 Outlet (DC12V)

Power
Adapter

Input AC110V-AC220V, output DC12V/1.5A

Power
Input

DC12V±10%, 1A(Max)

Power
Consumption

12W(Max)

USB
characteristics



Support             operating

system

Windows 7,Windows8,Windows10,Mac OSX, Linux

Video
Compression

H.265, H.264, MJPG

USB          communication

protocol

UVC

PTZ
Parameter



Pan/Tile
Rotation

-170°~+170°, -30°~+30°

Pan/Tile
Controller Speed

0.1~60°/Second, 0.1~30°/Second

Preset Speed

Pan:60°/Second, Tilt: 30°/Second

Preset Numbers

255 Points Preset (10 points By Remote
Controller)

Other
Parameter



Working
Voltage



12V

Working
current



0.25A(max)

Power
Consumption



2.5W(max)



Specifications subject to change without notice.
