SKU: ND-18G-WP-HUC-70M-KT

$795.00 ex GST

This wall plate is a 2 x 1 switcher and HDBaseT transmitter with HDMI and USB-C input. It features a US one-gang enclosure for a Decora-style wall plate. The USB-C input provides an ideal AV interface for connecting with new Apple notebooks and Windows® PCs as well as smartphones and tablets. Support video resolution up to 4K@60Hz 4:4:4. The input plate is remotely powered by the receiver or other HDBaseT-equipped devices via POE.

Key Features

  • Compliant with HDMI 2.0b, HDCP 2.2 and DisplayPort 1.2a

  • Support 18Gbps video bandwidth ☆ Video resolution up to 4K@60Hz 4:4:4

  • HDBaseT output can extend video transmission distance up to 70m for 1080P or 40m for 4K via a single CAT6/6a/7 cable

  • Support HDR10 and HDR10+

  • Audio formats support Dolby Atmos, TrueHD, Digital+, Digital; DTS X, HD Master Audio, HD High Resolution Audio, 5.1; PCM 2-8Ch

  • Support HDMI and USB-C input

  • US one-gang enclosure for Decora-style wall plate

  • Input signal selection supports automatic mode and manual mode

  • USB2.0 extension with Receiver

  • Support POE function (only from Receiver to Transmitter)

  • With USB-C charger input loop through port

Package Contents

  • 1× 18Gbps HDBaseT 70M with USB-C/HDMI & KVM Function Wall Plate Transmitter.
  • 1 ⅹ 18Gbps HDMI over HDBaseT Extender (Receiver) with HDMI / HDBT input auto switch
  • 2 ⅹ Mounting Ears
  • 2 ⅹ 3-pin Phoenix connector
  • 1 ⅹ 24V/1A Locking Power Adaptor
  • 1 ⅹ User Manual

Key Features

  • Compliant with HDMI 2.0b, HDCP 2.2 and DisplayPort 1.2a

  • Support 18Gbps video bandwidth

  • Video resolution up to 4K@60Hz 4:4:4

  • HDBaseT output can extend video transmission distance up to 70m for 1080P or 40m for 4K via a single CAT6/6a/7 cable

  • Support HDR10 and HDR10+

  • Audio formats support Dolby Atmos, TrueHD, Digital+, Digital; DTS X, HD Master Audio, HD High Resolution Audio, 5.1; PCM 2-8Ch

  • Support HDMI and USB-C input

  • US one-gang enclosure for Decora-style wall plate

  • Input signal selection supports automatic mode and manual mode

  • USB2.0 extension with Receiver

  • Support POE function (only from Receiver to Transmitter)

  • With USB-C charger input loop through port

Package Contents

  • 1× 18Gbps HDBaseT 70M with USB-C/HDMI & KVM Function Wall Plate Transmitter.
  • 1 ⅹ 18Gbps HDMI over HDBaseT Extender (Receiver) with HDMI / HDBT input auto switch
  • 2 ⅹ Mounting Ears
  • 2 ⅹ 3-pin Phoenix connector
  • 1 ⅹ 24V/1A Locking Power Adaptor
  • 1 ⅹ User Manual
